Static contact angle measurement involves the placement of microliter sized droplets on a sample surface. The angle formed at the boundary of the droplet is the contact angle, which characterizes a surface’s wettability. Dynamic contact angle measurements quantify contact angle hysteresis (the difference between advancing and receding contact angles), roll-off angle and absorption which can be useful for both non-absorbing and sponge-like materials. The single atomic layer sensitivity makes contact angle measurement ideal for surface cleanliness and contamination detection for medical devices, fabrics, thin films and wafers.

Kyowa sells a range of high quality instruments to measure contact angle to meet a variety of testing needs.


DM-CE1

product-kyowa-dm-ce1

  • Applicable sample size is up to 100 x 100mm
  • Manual movement stage in X and Z axis
  • Compact design: foot print 194 x 380 (W x D) at 3.1kg
  • Powerful performance with the fast image capture system of 60fps with progressive scan
  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancing/receding angles under captive drop[Automatic dispenser at option is required.]
    Sliding method: Advancing/receding angles under tilted surface [Option of DMs-601/401]
    Three-state method: Bubble or oil droplet in water, or vice versa [Option]
  • Measurement of Surface/Interfacila Tension by Pendant Drop method [Optional kit needed]
  • Surface free energy analysis [Optional kit recommended]
  • Fast image capture system 60fps
  • Automatic dispenser [Option]
  • Zoom lens [DMs-601/401 only]
  • Temperature control systems for solid and droplet [Option of DMs-601/401]

DMS-601/ DMs-401

product-kyowa-dms-601-dms-401

  • Applicable sample size is up to 150 x 100mm (W x D)
  • Manual movement stage in X and Z axis (DMs-601 moves stage automatically in Z axis)
  • Computer controlled automatic despenser discharges precise volume of droplet in 0.1uL resolution. (DMs-601)
  • Basic configuration includes Zoom lens
  • Optional accessories available for sliding method measurement and temperature control
  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancing/receding angles under captive drop[Automatic dispenser at option is required.]
    Sliding method: Advancing/receding angles under tilted surface [Option of DMs-601/401]
    Three-state method: Bubble or oil droplet in water, or vice versa [Option]
  • Measurement of Surface/Interfacila Tension by Pendant Drop method [Optional kit needed]
  • Surface free energy analysis [Optional kit recommended]
  • Fast image capture system 60fps
  • Automatic dispenser [Option]
  • Zoom lens [DMs-601/401 only]
  • Temperature control systems for solid and droplet [Option of DMs-601/401]

DM701

product-kyowa-dm701

  • Applicable sample size is up to 150mm x 150mm.
  • Computer controlled stage and dispenser perform measureemnts of multiple points automatically with single command.
  • Even advancing/receding angle measurements by the extension/contraction method and the sliding method (option) allow measurement of multiple points automatically with single command.
  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
    Sliding method: Advancing/receding angles with tilted surface [Option]
    Dynamic sliding method: Focusing the speed of droplet sliding [Option]
    Three-state method: Bubble or oil droplet in water, or vice versa [Option]
  • Measurement of Surface/Interfacial Tension by Pendant Drop method [Optional kit needed]
  • Surface free energy analysis [Optional kit recommended]
  • Fast image capture system (Standard max. 60fps, Option max. 1,000fps)
  • Automatic dispenser
  • Zoom lens
  • Temperature control systems for solid and droplet [Option]
  • Multi dispensers for surface free energy analysis [Option]

DM- 501

product-kyowa-dm-501

  • Applicable sample size is up to 150mm x 150mm.
  • Computer controlled automatic dispenser discharges precise volume of droplet in 0.1µL resolution.
  • Applicable to wide variety of optional accessories to extend the capability.
  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
    Sliding method: Advancing/receding angles with tilted surface [Option]
    Dynamic sliding method: Focusing the speed of droplet sliding [Option]
    Three-state method: Bubble or oil droplet in water, or vice versa [Option]
  • Measurement of Surface/Interfacial Tension by Pendant Drop method [Optional kit needed]
  • Surface free energy analysis [Optional kit recommended]
  • Fast image capture system (Standard max. 60fps, Option max. 1,000fps)
  • Automatic dispenser
  • Zoom lens
  • Temperature control systems for solid and droplet [Option]
  • Multi dispensers for surface free energy analysis [Option]

DM-701R

product-kyowa-dm-701r

  • Applicable sample size is up to 12 inch (300mm).round shape.
  • Round shape stage with 360 degree operation and reference angle indicator
  • Computer controlled stage and dispenser perform measureemnts of multiple points automatically with single command.
  • Even advancing/receding angle measurements by the extension/contraction method and the sliding method (option) allow measurements of multiple points automatically with single command.
  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
    Sliding method: Advancing/receding angles with tilted surface [Option]
    Three-state method: Bubble or oil droplet in water, or vice versa [Option]
  • Measurement of Surface/Interfacial Tension by Pendant Drop method [Optional kit needed]
  • Surface free energy analysis [Optional kit recommended]
  • Fast image capture system (Standard max. 60fps, Option max. 1,000fps)
  • Automatic dispenser
  • 360 degree stage rotation and reference angle indicator
  • Zoom lens
  • Multi dispensers for surface free energy analysis[Option]

DM-501R

product-kyowa-dm-501r

  • Applicable sample size is up to 12 inch (300mm).round shape.
  • Round shape stage with 360 degree operation and reference angle indicator
  • Computer controlled automatic dispenser discharges precise volume of droplet in 0.1µL resolution.
  • Applicable to wide variety of optional accessories to extend the capability.
  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
    Sliding method: Advancing/receding angles with tilted surface [Option]
    Three-state method: Bubble or oil droplet in water, or vice versa [Option]
  • Measurement of Surface/Interfacial Tension by Pendant Drop method [Optional kit needed]
  • Surface free energy analysis [Optional kit recommended]
  • Fast image capture system (Standard max. 60fps, Option max. 1,000fps)
  • Automatic dispenser
  • 360 degree stage rotation and reference angle indicator
  • Zoom lens
  • Multi dispensers for surface free energy analysis[Option]

LCD-400S

product-kyowa-lcd-400s

Applicable sample size 400 x 400mm

  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
  • Surface free energy analysis [Option]
  • Fast image capture system (Standard max. 60fps)
  • Automatic dispenser
  • Automatic operation of droplet placement

LCD-700S

product-kyowa-lcd-700s

Applicable sample size 700 x 700mm

  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
  • Surface free energy analysis [Option]
  • Fast image capture system (Standard max. 60fps)
  • Automatic dispenser
  • Automatic operation of droplet placement

LCD-900S

product-kyowa-lcd-900s

Applicable sample size 900 x 700mm, the unit includes the installation table.

  • Measurement of Contact Angle
    Sessile Drop method: Typical contact angle in static and time function
    Extension/Contraction method: Advancin/receding angles under captive drop
  • Surface free energy analysis [Option]
  • Fast image capture system (Standard max. 60fps)
  • Automatic dispenser
  • Automatic operation of droplet placement

PCA-1

product-kyowa-pca-1

The PCA-1 is designed to measure contact angles by placing the device on an object. The hand-held sized body with 650g light weight allows measurements of the objects under the conditions below:

  • Large sized panels and objects that are not allowed to be separated into small sample sizes
  • Coating of automobiles and buildings
  • Parts of the human body
  • Measurements in the field
  • One click conducts fully automated operations; Deposition of a droplet of preset volume and determination of contact angle at once.
  • Simple replacement of syringe and liquid sample
  • Time-based measurements by image capture of 30 fps
  • Surface free energy analysis and surface tension measurement by pendant drop method
  • Visible needle tip allows to capture target point precisely.

FPD-CP1

product-kyowa-fpd-cp1

FPD-CP1 is developed as the successor of FPD-MH20 discontinued.  This system is composed of measuring head, control circuit, and analysis software to measure contact angle, and designed to be equipped on an instrument that has a working sample stage.  Data transmission through RS232C is possible.

The system is specially designed to observe droplet with lateral image capturing system basically but the USB camera system is built in a slight upper section at a slant.  It allows to measure contact angle of large sized flat panels like LCD, OLED and wafers according to the capacity of sample stage of the host instrument.

FPD-MH20 cannot measure contact angle larger than 90° because of top view analysis system, but FPD-CP1 does not have the restriction thanks to the lateral image capturing system.

  • Save installation space and costs
  • Ideal method for large sized samples
  • No restriction of sample size
  • Contact angle is sensitive enough to show differences of even a monolayer order of organic contamination

MCA-3

product-kyowa-mca-3

With an adaptable micrometer capillary dispensing system, the MCA-3 enables the generation of Nano and Pico droplets. This state of the art system allows measurements of a micro area within 100μm wide. In addition, it can determine whether the wetting behavior of droplet is altered with a droplet volume in the range of Micro, Nano and Pico liters.

  • Top view camera and the capillary system allows for the pinpointed measurement and the observation of droplet spreading
  • High magnification lens and x12 zoom allows for a field of view approximately 75 x 56μm to 900 x 670μm.
  • Accurate measure of droplet size, volume and contact angle
  • Fast image capture system allows accurate measurements even with the quick evaporation of very small droplets.
  • Ink jet head system is optionally available.
  • Jacket type stage: Controls temperature of solid sample with water circulator bath
  • High speed image capture system: Up to 1000fps with optional camera upgrade
  • Ink jet head system: Droplet is generated by the ink jet of piezoelectric technology instead of capillary

For more information, please visit http://www.face-kyowa.co.jp/english/en_products/en_contact_angle/
